IC698ACC701工控继电模块PLC库存

产品介绍Product introduction

产品信息

• 产品类别：模块卡件

• 品牌：DCS、PLC

• 电话：15270269218

  联系人：叶经理

• 质保期：1年

• 加工定制：不可定制

• 产地/厂家：美国

产品实拍图Product picture

名称：LCD显示设置范围单位：出厂

背景

莫迪夫。

F2.00启动模式启动模式

0：以启动频率启动

1： 首先制动，然后以起动频率起动

2： 即时启动（包括方向判断），从

转速为零时的起动频率

注：启动过程包括打开驱动器

电源故障后***次恢复交流电源，

外部故障和滑行停止时复位

1 0 ×

F2.01启动频率启动频率0.20~60.00Hz 0.01Hz 0.50Hz○

F2.02启动频率保持

时间

保持时间0.0~10.0s 0.1s 0.0s○

F2.03直流注入制动

起动电流

吹牛

开始

取决于驱动器的类型

P型：驱动器额定电流的0.0～80.0%

G型：0.0～100.0%驱动器额定电流

0.1% 0.0% ○

附录1参数93

EV2000系列通用变速驱动用户手册

F2组：启动和制动参数

对位。名称：LCD显示设置范围单位：出厂

设置Modif。

F2.04直流注入制动

开始时间

制动时间0.0（禁用），0.1～30.0s 0.1s 0.0s○

F2.05加速/减速

g模式选择

ACC/DEC模式

0：线性加速/减速模式

1： S曲线

2： 自动加速/减速

1 0 ×

F2.06 S曲线起始段S曲线起始

秒

10.0%~50.0%（Acc/Dec时间）

F2.06+F2.07≤90% 0.1% 20.0% ○

F2.07 S曲线上升时间S曲线上升10.0%~80.0%（Acc/Dec时间）

F2.06+F2.07≤90% 0.1% 60.0% ○

F2.08停止模式停止模式

0:12月停止

1： 停下来

2： Dec停止加直流注入制动

1 0 ×

F2.09直流注入制动

停止时的初始频率INI BRAK FREQ 0.00~60.00Hz 0.01Hz 0.00Hz○

F2.10直流注入制动

车站等候时间

制动等待时间0.00~10.00s 0.01s 0.00s○

F2.11直流注入制动

停止电流

吹牛

停止

取决于驱动器的类型

P型：驱动器额定电流的0.0～80.0%

G型：0.0～100.0%驱动器额定电流

0.1% 0.0% ○

F2.12直流注入制动

停车时间

刹车时间

停止0.0（禁用），0.1～30.0s 0.1s 0.0s○

F2.13动态制动制动单元选择0：未使用动态制动

1： 采用动态制动

1 0 ×

F2.14

工作时间比

驱动器的制动套件

总工作时间

制动器的效用

单位

0.0~100.0%

注：适用于5.5/7.5kW驱动器的内置制动套件

在Dec过程中应采用动态制动

0.1% 2.0% ×

F3组：辅助参数

对位。名称：LCD显示设置范围单位：出厂

设置Modif。

F3.00运行反向禁用运行反向禁用0：运行反向启用1：运行反向禁用1 0×

F3.01反向/向前行驶，停止

时间

FWD/REV死区时间0~3600s 0.1s 0.0s○

F3.02保留保留-0*

F3.03保留保留-0*

F3.04保留保留-0*

F3.05汽车节能

活动

节能OPR 0:禁用1:启用1 0×

F3.06 AVR功能AVR功能0:禁用1:启用

2： 减速过程中禁用

1 2 ×

F3.07滑差补偿增益滑差补偿

增益0.0%~300.0%、0.1%和100.0%○

F3.08滑差补偿极限滑差补偿

极限

0.0%~250.0% 0.1% 200.0% ○

F3.09补偿时间补偿时间

常数

0.1~25.0s 0.1s 2.0s

F3.10载波频率

载波频率的调整

G型：5.5kW～45kW

P型：7.5kW～55kW:15k～3k

G型：55kW～90kW

P型：75kW～110kW:10k～1k

G型：110kW～220kW

P型：132kW～280kW:6k～0.7k

0.1kHz

8.0kHz

3.0kHz

2.0kHz

○

F3.11载波频率

自动调谐

载波频率

规则SELE

0:禁用

1： 启用

1 1 ○

94附录1参数

EV2000系列通用变速驱动用户手册

F3组：辅助参数

对位。名称：LCD显示设置范围单位：出厂

设置Modif。

F3.12电机音调调整电机调谐0~10 1 0○

F3.13点动频率点动操作频率0.10~50.00Hz 0.01Hz 5.00Hz○

F3.14点动间隔点动间隔时间0.0~100.0s 0.1s 0.0s○

F3.15点动操作的Acc时间点动Acc时间

F3.16点动操作的12点时间点动12点时间

0.1~60.0s 0.1○

F3.17附件时间2附件时间2

F3.18十二月时间2十二月时间2

F3.19加速时间3加速时间3

F3.20十二月时间3十二月时间3

F3.21附件时间4附件时间4

F3.22十二月时间4十二月时间4

0.1~3600

注：

默认单位为秒；Acc/Dec时间单位由F9.09决定

0.1

5.5kW~

22kWG：

6.0

30kW~

280kWP：

20.0

○

F3.23预设频率1多频带频率1 5.00Hz

F3.24预设频率2多频带频率2 10.00Hz

F3.25预设频率3多频带频率3 20.00Hz

F3.26预设频率4多频带频率4 30.00Hz

F3.27预设频率5多频带频率5 40.00Hz

F3.28预设频率6多频带频率6 45.00Hz

F3.29预设频率7多频带频率7

F0.13（频率下限）~F0.12（频率上限）0.01Hz

50.00Hz

○

F3.30跳频1跳频0.00~650.0Hz 0.01Hz 0.00Hz

F3.31跳频范围1跳频频带1 0.00~30.00Hz 0.01Hz 0.00Hz

F3.32跳频2跳频2 0.00~650.0Hz 0.01Hz 0.00Hz

F3.33跳频范围2跳频频带2 0.00~30.00Hz 0.01Hz 0.00Hz

F3.34跳频3跳频3 0.00~650.0Hz 0.01Hz 0.00Hz

F3.35跳频范围3跳频带3 0.00~30.00Hz 0.01Hz 0.00Hz

F4组：运行参数

参数名称LCD

Name LCD Display Setting range Unit Factory

setting

Modif.

F2.00 Start mode START MODE

0:start at start frequency

1:brake first, then start at start frequency

2:Start on the fly(including direction judgement), start at

start frequency when speed is zero

Note: Starting process includes switching on the drive for

the first time, recover of AC supply after power failure,

reset upon external fault and coast-to-stop

1 0 ×

F2.01 Start frequency START FREQ 0.20~60.00Hz 0.01Hz 0.50Hz ○

F2.02 Start frequency holding

time

HOLD TIME 0.0~10.0s 0.1s 0.0s ○

F2.03 DC injection braking

current at start

BRAK CURR AT

START

Depending on the type of the drive

P type: 0.0～80.0% of drive’s rated current

G type: 0.0～100.0% of drive’s rated current

0.1% 0.0% ○

Appendix 1 Parameters 93

EV2000 Series Universal Variable Speed Drive User Manual

Group F2: Starting and Braking Parameters

Para. Name LCD Display Setting range Unit Factory

setting Modif.

F2.04 DC injection braking

time at start

BRAK TIME 0.0 (disabled), 0.1～30.0s 0.1s 0.0s ○

F2.05 Accelerating/deceleratin

g mode selection

ACC/DEC MODE

0:Linear Accelerating / decelerating mode

1:S curve

2:Auto Accelerating/decelerating

1 0 ×

F2.06 Start section of S curve S CURVE START

SEC

10.0%~50.0%(Acc/Dec time)

F2.06+F2.07≤90% 0.1% 20.0% ○

F2.07 Rising time of S curve S CURVE UP 10.0%~80.0%(Acc/Dec time)

F2.06+F2.07≤90% 0.1% 60.0% ○

F2.08 Stopping Mode STOP MODE

0: Dec to stop

1: Coast to stop

2: Dec to stop plus DC injection braking

1 0 ×

F2.09 DC injection braking

initial frequency at stop INI BRAK FREQ 0.00~60.00Hz 0.01Hz 0.00Hz ○

F2.10 DC injection braking

waiting time at stop

BRAK WAIT TIME 0.00~10.00s 0.01s 0.00s ○

F2.11 DC injection braking

current at stop

BRAK CURR AT

STOP

Depending on the type of the drive

P type: 0.0～80.0% of drive’s rated current

G type: 0.0～100.0% of drive’s rated current

0.1% 0.0% ○

F2.12 DC injection braking

time at stop

BRAK TIME AT

STOP 0.0 (disabled), 0.1～30.0s 0.1s 0.0s ○

F2.13 Dynamic braking BRAK UNIT SELE 0: Dynamic braking is not used

1: Dynamic braking is used

1 0 ×

F2.14

Ratio of working time of

braking kit to drive’s

total working time

UTILITY OF BRAK

UNIT

0.0~100.0%

Note: valid for the built-in braking kit of 5.5/7.5kW drive

and dynamic braking should be applied in Dec process

0.1% 2.0% ×

Group F3: Auxiliary parameters

Para. Name LCD Display Setting range Unit Factory

setting Modif.

F3.00 Run reverse disabled RUN REV DISABLE 0:Run reverse enabled 1:Run reverse disabled 1 0 ×

F3.01 Run reverse/forward dead

time

FWD/REV DEAD TIME 0~3600s 0.1s 0.0s ○

F3.02 Reserved RESERVED - - 0 *

F3.03 Reserved RESERVED - - 0 *

F3.04 Reserved RESERVED - - 0 *

F3.05 Auto energy saving

operation

ENERGY-SAVING OPR 0:disabled 1:enabled 1 0 ×

F3.06 AVR function AVR FUNC 0: disabled 1:enabled

 2: disabled in decelerating process

1 2 ×

F3.07 Gain of Slip compensation SLIP COMPENSATION

GAIN 0.0%~300.0% 0.1% 100.0% ○

F3.08 Slip compensation limit SLIP COMPENSATION

LIMIT

0.0%~250.0% 0.1% 200.0% ○

F3.09 Compensation time COMPENSATION TIME

CONST

0.1~25.0s 0.1s 2.0s ×

F3.10 Carrier frequency

adjustment CARRIER FREQ

Type G: 5.5kW～45kW

Type P: 7.5kW～55kW: 15k～3k

Type G: 55kW～90kW

Type P: 75kW～110kW: 10k～1k

Type G: 110kW～220kW

Type P: 132kW～280kW: 6k～0.7k

0.1kHz

8.0kHz

3.0kHz

2.0kHz

○

F3.11 Carrier frequency

auto-tuning

CARRIER FREQ

REGULATION SELE

0:disabled

1:Enabled

1 1 ○

94 Appendix 1 Parameters

EV2000 Series Universal Variable Speed Drive User Manual

Group F3: Auxiliary parameters

Para. Name LCD Display Setting range Unit Factory

setting Modif.

F3.12 Motor tone adjustment MOTOR TUNING 0~10 1 0 ○

F3.13 Jog frequency JOG OPR FREQ 0.10~50.00Hz 0.01Hz 5.00Hz ○

F3.14 Jog interval JOG INTERVAL TIME 0.0~100.0s 0.1s 0.0s ○

F3.15 Acc time of Jog operation JOG ACC TIME

F3.16 Dec time of Jog operation JOG DEC TIME

0.1~60.0s 0.1 ○

F3.17 Acc time 2 ACC TIME2

F3.18 Dec time 2 DEC TIME2

F3.19 Acc time 3 ACC TIME3

F3.20 Dec time 3 DEC TIME3

F3.21 Acc time 4 ACC TIME4

F3.22 Dec time 4 DEC TIME4

0.1~3600

Note:

Default unit is second; unit of Acc/Dec time is decided by F9.09

0.1

5.5kW~

22kWG:

6.0s

30kW~

280kWP:

20.0s

○

F3.23 Preset frequency 1 MULTIBAND FREQ 1 5.00Hz

F3.24 Preset frequency 2 MULTIBAND FREQ 2 10.00Hz

F3.25 Preset frequency 3 MULTIBAND FREQ 3 20.00Hz

F3.26 Preset frequency 4 MULTIBAND FREQ 4 30.00Hz

F3.27 Preset frequency 5 MULTIBAND FREQ 5 40.00Hz

F3.28 Preset frequency 6 MULTIBAND FREQ 6 45.00Hz

F3.29 Preset frequency 7 MULTIBAND FREQ 7

F0.13 (Lower limit of frequency) ~F0.12(upper limit of frequency) 0.01Hz

50.00Hz

○

F3.30 Skip frequency 1 SKIP FREQ1 0.00~650.0Hz 0.01Hz 0.00Hz ×

F3.31 Range of skip frequency 1 SKIP FREQ BAND1 0.00~30.00Hz 0.01Hz 0.00Hz ×

F3.32 Skip frequency 2 SKIP FREQ2 0.00~650.0Hz 0.01Hz 0.00Hz ×

F3.33 Range of skip frequency 2 SKIP FREQ BAND2 0.00~30.00Hz 0.01Hz 0.00Hz ×

F3.34 Skip frequency 3 SKIP FREQ3 0.00~650.0Hz 0.01Hz 0.00Hz ×

F3.35 Range of skip frequency 3 SKIP FREQ BAND3 0.00~30.00Hz 0.01Hz 0.00Hz ×

Group F4: Operating Parameters

Para Name LCD Display Setting range Unit Factory

setting

Modif.

F4.00

PLC operation

mode

selection

PLC OPR

MODE

Unit’s place of LED: PLC operation mode

0:disabled 1:Stop after operating for 1 cycle

2: Holding at the final value after single cycle of operation

3:Operate continuously

Ten’s place of LED: Restarting mode after stopping

0:Run again from phase 1

1:Continue to run from the stopping phase

2:Operate at the time and frequency when the drive stops or fault occurs

Hundred’s place of LED: Save at power off

0:Not saving

1:Save the time and frequency at power off

Thousand’s place of LED: selecting the unit of time

0:second 1:Minute

1 0000 ×

F4.01 Phase 1 setup STAGE 1

SET

Unit’s place of LED: Frequency setting

0:Pre-set frequency 1(F3.23) 1:Decided by F0.00 parameter

2:Close loop reference 1(F5.20) 3:Decided by F5.01 parameter

Ten’s place of LED: Running direction selection

0:Run forward 1:Run reverse

2:Decided by operating instructions

Hundred’s place of LED:Acc/Dec time selec
